ASTM A694 F60 Forged Flange
GNEE is the manufacturer, supplier and exporter of ASTM A694 F60 Carbon Steel Flanges, these pipes are made of high quality raw material. GNEE products are designed in accordance with major international standards and sold to many countries around the world.
ASTM A694 F60 flanges are carbon and alloy steel flanges. ASTM A694 F60 forged flanges are made from F60 duplex steel. Carbon steel ASTM A694 F60 flanges have high durability and tensile strength due to the presence of carbon, manganese, phosphorus, sulfur and silicon in the material composition. In particular, the flange contains 1.6% manganese.
ASTM A694 F60 High Temperature Flange is a high strength product made from mild steel designed to withstand high pressure and high temperature applications. These flanges are used in industries where high temperature, pressure and corrosive working conditions are severe, such as oil and gas pipelines, refineries and power plants.
Take ActionContact Us: sales@gneetube.com
ASTM A694 F60 High Yield Carbon Steel Pipe Flange Product information
ASTM A694 Carbon Steel Grade F60 Forged Flange Standard Specification
| Specification | ASTM A694 / ASME SA694 |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Size | 1/2"NB TO 64"NB |
| Flange Face Type | Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| Value Added Services | CNC Machining, Cold and Hot Dip Galvanized, Yellow Transparent, Drill, Oil Black Paint, Rolling, Zinc Plated, Anti-rust Paint, Shot Blasting, Sand Blasting, Heat Treatment, Punch |
ASTM A694 Grade F60 Spiral Flanges Chemical Composition
| ASTM A694 | Grade F60 |
| C | ≤0.30 |
| Mn | ≤1.60 |
| P | ≤0.025 |
| S | ≤0.025 |
| Si | 0.15-0.35 |
ASTM A694 F60 socket weld flanges Mechanical Properties
| ASTM A694 | Grade F60 |
| Yield Strength min. | 415 MPa [60 ksi] |
| Tensile Strength min. | 515 MPa [75 ksi] |
| Elongation min. | 20 |
ASTM A694 F60 long weld neck flange
Why choose us
gnee is one of the professional manufacturers of export fittings and steel products in China, which is committed to providing customers with the best quality ASTM A694 F60 Industrial Flanges and the most sincere service. The main markets are from 60 countries.
GneeGroup participated in the exhibition
FAQ
1. One-stop solution
We have thousands of total production experiences, from raw materials to finished products.
2. Competitive price
Large-scale procurement, standardized production processes and efficient management make our prices competitive.
3.Fast shipping
Years of export experience enable us to control shipping time more accurately.
4.Quality control
Standardized production process, perfect management system, professional testing equipment, and customization of special materials.
