ASTM A200 Alloy Steel Tubes for Refinery Use
ASTM A200 Alloy Steel Tubes for Refinery Use
A200 seamless steel pipe refers to a steel pipe with a hollow section and no seams around it. It is a commonly used seamless steel pipe model.
ASTM A200 Alloy Steel Pipe covers several grades in minimum wall thickness (mw), Chromium Molybdenum and Chromium Molybdenum Silicon, Seamless, Hot Finished and Cold Finished, Intermediate Alloy Steel Pipe for conveying fluid types at various high temperatures and pressures heaters in which the tubes may be subjected to higher furnace temperatures than the fluid contained.
A200 seamless alloy steel pipe is made by perforating steel ingots or solid tube blanks into capillary tubes, and then hot rolling, cold rolling or cold drawing. SA200 Alloy Boiler Tube This specification covers tubing with an outside diameter of 2 to 9 inches (50.8 to 228.6 mm) and a minimum wall thickness exceeding 0.220 inches (5.59 mm). Due to its excellent physical properties and corrosion resistance, it is widely used in transmission pipelines and pressure vessels in petroleum, natural gas, chemical industry, electric power and other industries.
Chemical Composition(%):
| Grade | C | Si | Mn | P | S | Cr | Mo |
|---|---|---|---|---|---|---|---|
| T5 | 0.12 max | 0.50 max | 0.30–0.60 | 0.025 max | 0.025 max | 4.00-6.00 | 0.44-0.65 |
| T11 | 0.05-0.15 | 0.50-1.00 | 0.30–0.60 | 0.025 max | 0.025 max | 1.00-1.50 | 0.44-0.65 |
ASTM A200 Boiler Tube Mechanical Properties
| Yield Rp0.2 (MPa) |
Tensile Rm (MPa) |
Impact KV/Ku (J) |
Elongation A (%) |
Reduction in cross section on fracture Z (%) |
As-Heat-Treated Condition | Brinell hardness (HBW) |
|---|---|---|---|---|---|---|
| 692 (≥) | 147 (≥) | 23 | 21 | 31 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 342 |
ASTM A200 Alloy Steel Tubes
Specifications
Standard: JIS, AISI, ASTM, GB, DIN, EN
Model Number: T11,T12,T2,T22,T5,T9,P2,P12,P11,P22,P5,P9,P91etc
Type: seamless and welded or random
Steel Grade: alloy steel pipe
Application: industry
Certification: ISO&SGS
Thickness: 1mm~120mm
Outer Diameter: 6mm~2400mm
length: 12m,11.8m,6m,as requirement
Packing: Bare packing/bundle packing/crate packing/wooden protection at the both sides of tubes and suitably protected for sea-worthly delivery or as requested.
gnee company has established long-term cooperative relationships with well-known domestic steel mills such as Chengdu Iron and Steel Group, Baosteel Group, Anshan Iron and Steel Group, Tianjin Seamless, etc. Suitable for electric power, metallurgy, city gas, thermal pipe network, shipbuilding and other industries.
