EN 10216-2 10CrMo9-10 High Temperature Steel Pipe
GNEE's EN 10216-2 10CrMo9-10 Seamless Steel Tube For Pressure is produced using various manufacturing processes, including hot working or cold working, and then the pipe is subjected to various tests, such as flattening test, water pressure test or non-destructive electrical test, to ensure that the specified requirements are met.
EN10216-2 10CrMo9-10 high temperature alloy seamless steel pipe uses iron, chromium and molybdenum as the main elements, which can form a dense chromium oxide layer on the surface of the steel to effectively prevent further oxidation reactions. EN10216-2 10CrMo9-10 high temperature seamless pipe has the characteristics of high strength, corrosion resistance, good processability and good high temperature resistance.
Therefore, EN10216-2 10CrMo9-10 heat-resistant steel pipe can be used in power station boilers, steam boiler equipment, large pressure pipelines and other occasions that need to withstand high temperature and high pressure.
Take ActionContact Us: sales@gneetube.com
EN10216-2 Chemical Composition:
| Steel grade | C | Si | Mn | P | S | Cr | Mo | Ni | Altot | Cu | Ti max | |
| Steel name | Steel number | max | max | |||||||||
| 10CrMo9-10 | 1.7380 | 0.08-0.14 | 0.08-0.14 | 0.30-0.70 | 0.025 | 0.020 | 2.00-2.50 | 0.90-1.10 | =0.30 | =0.040 | =0.30 | |
EN10216-2 Mechanical Property:
| Steel grade | Tensile properties at room temperature | Impact properties a b | |||||||||||
| Steel name | Steel Number | T≤16 | 160<T≤40 | 40<T≤60 | 60<T≤100 | l | t | l | t | ||||
| MPa | MPa | MPa | MPa | MPa | 20 | 0 | -10 | 20 | 0 | ||||
| 10CrMo9-10 | 1.7380 | 280 | 280 | 270 | 480-630 | 22 | 20 | 40 c | 27 c | ||||
10CrMo9-10 High Precision Pipes
Why choose usG
Gnee company covers an area of 35,000 square meters and has more than 200 employees, including 80 technical staff. We have established an effective and complete quality control and assurance system. The company has also obtained ISO9001 quality system certification.
Gnee Customer visit
FAQ
1.Q.What's your advantage?
A.Honest business with competitive price and professional service on export process.
2.Q.Can your products be customized?
A.Yes, we can produce and process according to your requirements.
3.Q. Do you have a quality control system?
A.Yes, we have our own quality control laboratory.
